S3009 Radiator Valve

Short Description:

Working pressure:1.0MPa

Working temperature: -20℃≤t≤110℃

Working Medium:Water, Non-corrosive liquid, Saturated steam

Thread confirmed to ISO228

Send email to us Download as PDF

Product Detail

Product Tags

Product information :

Product name	Brass Ball Valve
Sizes	1/2"~2"
Bore	Full bore
Application	Water, oil, and other non-corrosive liquid
Working pressure	PN30 / 500Psi
Working temperature	-10 to 110°C
Working durability	10,000 cycles
Quality standard	EN13828, EN228-1
End Connection	BSP, NPT
Features:	Heavy-duty design for higher pressure
	Anti-blow-out stem structure
	100% leakage test for each valve
	OEM production acceptable
Materials	Spare Part	Material
	Body	Forged brass, sandblasted and nickel-plated
	Bonnet	Forged brass, sandblasted and nickel-plated
	Ball	Forged brass, polished and chrome-plated
	Handle	Steel chromed with plastic cover
	Nut	Steel
	Stem	Brass
	Ball seat	PTFE
Packing	Inner boxes in cartons, loaded in pallets
	Customized design acceptable

Bore sizes for check valves:

NO	Component	Material
1	Body	Brass
2	Union	Brass
3	O-ring	EPDM
4	Copper ring	Brass
5	Gasket	EPDM
6	Lock cap	Brass
7	Plug	Brass
8	Clamp ring	Stainless Steel
9	O-ring	EPDM
10	Lock cap	Brass
11	Packing	PTFE
12	Press cap	Brass
13	Stem	Brass
14	Handle wheel	ABS
15	O-ring	EPDM

SIZE	L	H	D	Weight
1/2"	50	72.5	45	230

Production flow of Brass Ball Valves :

Brass material Chemical composition used for brass ball valves:

Bore sizes for brass ball valves:

Available surface treatments of brass ball valves:

Packing of brass ball valves:

Testing Lab for brass ball valves:
